HH fin tube apply in waste heat recovery , boiler
Competitive Advantage:
- We have more than 10,000 square meters workshop, including 6 H-FIN
TYPE finning machines, daily extrusion capacity up to 20 tons.
- The Square or Rectangular Fins H-Finned Tubes are the preferred
tube choice for high pressure boilers.
- Fins can be manufactured by stamping process in almost any shape
and size.
- In-line fin and tube spacing allows for cleaning with excellent
choice in sooting or fouling atmospheres.
Base tube material: SA192 SMLS 31.8mmOD*2.9mmTHK*7260mmLG
Fin Material: CS; FPM67fins X 1.5 mm THK x 75 mm W x 160 mm H
Manufacturing Process:
It adopts high frequency welding spiral technology, the national
patent technology with high frequency power supplies as the heat
source to heat the steel strip, steel pipe at the same time,be
welded together
Reference Drawing :
Material: Steel, Carbon Steel, etc.
Bare tube OD: 25-63mm Fin Pitch: 8-30mm Fin Height: <200mm Fin Thick:
1.5-3.5mm
| Name | Base tube
(OD) mm | Fin Pitch
(mm) | length
(m) |
| Min | Max | Min | Max | Min | Max |
| Extruded aluminum fin tube | 12.7 | 51 | 2.1 | 10 | 0.5 | 20 |
| L/LL/KL aluminum fin tube | 19 | 51 | 2.1 | 3.2 | 0.5 | 15 |
| Embedded aluminum fin tube | 19 | 42 | 2.3 | 3.2 | 0.5 | 15 |
| Low fin tube | 12.7 | 32 | 0.8 | 2 | 0.5 | 20 |
| Spiral fin tube | 12.7 | 70 | | | 0.5 | 20 |
| ERW HF spiral fin tube | 16 | 219 | 3 | 25 | 0.5 | 28 |
| ERW HF spiral serrated fin tube | 16 | 219 | 3 | 25 | 0.5 | 28 |
| Serrated width(mm)
10 min~26 max | Serrated depth(mm)
4 min~16 max |
| ERW studded tube | 89 | 200 | 16 | 50 | 2 | 15 |
| | | | | | |
| DC ERW H/HH fin tube | 25 | 51 | 9 | 25 | 1 | 15 |
| H/HH fins | Length(mm)
60 min-150 max | Thickness(mm)
1.5 min~4 max | Width(mm)
30 min~50 max |
Application: waste heat recovery, petrochemical industry, power plant boiler,
economizer, coaches, civil building heating, refrigerating, drying,
medicine of wood drying, food drying system and other industries
Capacity: Six DC ERW H/HH fining lines, daily capacity around 20 tons;
Products&Inspection Deatails:
Check the outside diameter
Check the height distance
Check the height distance
Check the fin pitch distance
Following documentations should be reviewed & endorsed:
1. Declaration of conformity,
2. Inspection plan,
3. Welding book(WPS & PQR),
4. Finned tubes examination reports
(dimension & visual inspection, hardness test report, tensile test
report),
5. Test samples sheet,
6. Incoming inspection report,
7. Inspection certificate for bare tube,
8. Quality test certificate for steel strip,
9. Iinspection & Guarantee certificate for finned tube,
10. Product inspection report.
Packaging: sea worthy with plastic cap for each edge of core tube , finned
tubes shall be put on the metal frame with wooden walls and plastic
layer be considered between tubes rows to avoid damage and
deformation of the fins
Mass production of DC ERW HH fin tube
